VELUX GDL PK19 SK0W224 Roof Balcony System for Tiles - 198cm x 252cm

Code:
GDL PK19 SK0W224
Brand:
Free UK Delivery

This double CABRIO roof balcony system featuring 120mm universal tile flashing and triple glazing is an advanced, white-painted version of the triple-glazed CABRIO roof balcony system. Including VELUX CABRIO roof balcony, one GPL top-hung, one GIL FIXED element and flashings f... Read More

Create a wishlist

"Quick delivery and communication"

Stephen Taylor

Description

This double CABRIO roof balcony system featuring 120mm universal tile flashing and triple glazing is an advanced, white-painted version of the triple-glazed CABRIO roof balcony system. Including VELUX CABRIO roof balcony, one GPL top-hung, one GIL FIXED element and flashings for tiles up to 120mm in profile, this VELUX CABRIO roof balcony system transforms a roof window into an instantaneous balcony within seconds.

As a great way to add a real wow factor and value to your property, the lower section unfolds into a glazed balcony with side railings whilst the higher section is top hung and opens outwards. The upper top hung roof window can rotate 180° and lock into position for effortless cleaning of the exterior pane.

Features & Benefits: VELUX GDL PK19 SK0W224 Roof Balcony System for Tiles - 198cm x 252cm

  • Suitable for roof pitches between 35° and 53°
  • Triple glazing
  • Lacquered natural pine finish painted white
  • For tiles up to 120mm thick
  • 1.2 uValue
  • Universal tile flashing
  • GPL top-hung window
  • GIL FIXED element
  • BBA certified
  • 10-year guarantee on windows and flashings

Made from a high-quality natural pine core with a protective triple coat of clear lacquer, to help preserve the window's timber, and a white painted finish, this balcony system is outstanding value for money and straightforward to install. It has an easy-to-use top control bar for opening as well as ventilation purposes when the window is closed.

The --66 triple glazing is included as standard to ensure energy efficiency with a laminated internal pane and a toughened outer pane with an easy-to-clean, anti-dew layer to keep the windows cleaner for longer.

Please note:

  • If you required a Pine CABRIO roof balcony system, please call our sales team.
  • This is made up of a PK10 (upper) and a PK04 (lower) window if you are looking for blinds.

Dimensions

Size PK19 - 94 x 252cm Width 198cm

Details

Code GDL Type CABRIO balcony Finish White Painted Operation Manual
Glazing Triple Glazing Pitch 35 - 53 degrees U Value 1.2

Questions & Answers

Question:

Hi can the window section be fitted the either the right or left of the cabrio?

Answer:

I believe it's only as you see in the photos.

Question:

I can see above the PK19 cabrio with 1 side light weighs 305kg. Does this product come in two parts or as one combined unit.?

Answer:

The unit will come in parts to be assembled on site

Question:

Hi there What is the Weight of this unit

Answer:

The total weight of all components is approx 305kg.
