VELUX EDQ 0000 Single Metal Roof Flashing

Code:

VELUX-EDQ-0000

Brand:

Designed to integrate with your VELUX roof window with standing seam metal roof applications, this VELUX EDQ 0000 single flashing can offer a high-quality weathertight seal which allows effective rainwater drainage while sitting flush under your roofing material for a neat and... Read More

View full product details

View questions about this product

Create a wishlist

Frank

Description

This VELUX flashing is compatible with roofing panels that run vertically up your roof and join at the seams via a hidden fastener metal panel system.

Features & Benefits: VELUX EDQ 0000 Single Metal Roof Flashing

For use with metal roofs that are 25mm-40mm in profile
Durable, weatherproof and watertight seals
Sits flush under the roofing material for a neat appearance
Made from lacquered aluminium with a dark grey finish
For use with roof pitches between 15° and 90°
Range of size options
Easy to install

Please note:

Leaves and other debris should be removed from any flashing at least once a year to allow rainwater to run freely.

Specification

Dimensions

Length 980mm Depth 12mm Size CK01 - 55 x 70cm
CK02 - 55 x 78cm
CK04 - 55 x 98cm
CK06 - 55 x 118cm
FK04 - 66 x 98cm
FK06 - 66 x 118cm
FK08 - 66 x 140cm
MK04 - 78 x 98cm
MK06 - 78 x 118cm
MK08 - 78 x 140cm
MK10 - 78 x 160cm
MK12 - 78 x 180cm
PK04 - 94 x 98cm
PK06 - 94 x 118cm
PK08 - 94 x 140cm
PK10 - 94 x 160cm
SK06 - 114 x 118cm
SK08 - 114 x 140cm
SK10 - 114 x 160cm
UK04 - 134 x 98cm
UK08 - 134 x 140cm
UK10 - 134 x 160cm Width 1140mm
1340mm
550mm
55cm
660mm
780mm
940mm

Details

Code EDQ Height 700mm
780mm
980mm
1180mm
1400mm
1600mm
1800mm Thickness Up to 40mm Roof Covering Metal

Flashing Type Single Flashing

Downloads

There are no product downloads to show.

Questions & Answers

Question:

Where can I buy the extra flashing accessories for the bottom upstand between the standing seams and the small side flashing that picks up the overlap side sheets please?

Answer:

Please call in and speak with a member of the team

Question:

I am a builder in the USA and have found that Velux USA does not offer this flashing product. Their standard flashing system for metal roofs is ugly and not anything I would ever want to install on a client's home. Can anyone offer guidance about purchasing a skylight and flashing kit from the UK and installing overseas as it pertains to warranties, building codes etc.?

Answer:

We only ship within the UK

Question:

Hi what flashing kit do I need for a box profile roof

Answer:

You would use EDQ or you could use a ZWC - its best to check with Velux on 01592 778225
