SuperFOIL SFNC Non-Combustible Multi-Layer Foil Insulation 1.2m x 9.5m

Name: SuperFOIL SFNC Non-Combustible Multi-Layer Foil Insulation 1.2m x 9.5m
Brand: SuperFOIL
SKU: SF3320
Price: 400.80 GBP
Availability: InStock

Code:

SF3320

Brand:

SuperFOIL

As a reliable insulation option, this SuperFOIL SFNC Non-Combustible Multi-Layer Foil Insulation is the only non-combustible multifoil available on the market. It has been certified by BRE and achieved the highest rating (A1) under the latest European Fire Classification syste...Read More

View full product details

View questions about this product

£400.80 Incl. VAT Earn points

Est. Delivery: 1-2 Working Days

Shipping costs displayed in basket.

For delivery Tuesday, Jul 2nd - order in:

days hrs mins secs

Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.

View Transport Policy

View full product details

View questions about this product

Create a wishlist

Ruth Hobart

Description

This SuperFOIL SFNC Insulation is versatile for roofs, walls, and floors with an rValue of 1.54m²K/W in pitch roofs and 1.99m²K/W in walls (using air gaps). It can also be used over and under rafters for higher performance in a 'duet' format. It is also compatible with other insulation materials like mineral wool or foam board for combi installation to achieve the necessary insulation uValue.

Features & Benefits: SuperFOIL SFNC Non-Combustible Multi-Layer Foil Insulation 1.2m x 9.5m

9.5m length x 1.2m width x 20mm thickness once installed
10.02m² roll size
30kg weight per roll
Three layers
Thermal conductivity of 0.0318W/mK
Perfect choice for situations where fire resistance and insulation are necessary
Flame and fire retardant
Non-combustible

This product has excellent thermal resistance. Its rValues (air gaps included) are as follows: for roofs, the rValue is 1.54m²K/W; for walls, it is 1.99m²K/W; for floors, it is 3.46m²K/W; and the core rValue of this product is 0.62m²K/W.

Installation

Over Rafters: To install this SFNC SuperFOIL over rafters, roll out and staple at least 500mm (or as needed), and use reinforced tape to cover joints and overlap widths by at least 75mm (50mm to 100mm range). Cut and seal SuperFOIL around rafters and seal it to the cavity wall insulation or wall plate for an airtight envelope, then fix tiles, fix roofing battens parallel to rafters, and apply breathable roof underlay, all according to manufacturer's guidelines.
Under Rafters: If installing under rafters, roll out SuperFOIL on the rooftop, batten horizontally, staple at least 500mm (or as needed), and use reinforced tape to cover joints and overlap widths by at least 75mm (50mm-100mm range). Staple SFNC SuperFOIL onto the timber wall plate at the bottom of the roof pitch for an airtight envelope and fix battens across rafters with an air gap between SuperFOIL and plasterboard for optimal performance.

Please note:
