Manthorpe SmartVerge Polypropylene Dry Verge

Code:

MANTHORPE-SMARTVERGE-POLYPROPYLENE-DRY-VERGE

Brand:

Manthorpe

A UV-stabilised polypropylene dry verge system that is suitable for small and large format concrete interlocking tiles, from 382mm x 227mm up to 430mm x 380mm, on roof pitches between 15° and 55°, this Manthorpe SmartVerge® Polypropylene Dry Verge is easy to install without th... Read More

View full product details

View questions about this product

Colour

Left or Right Handed

from

£2.24 Incl. VAT

Earn points

Delivery from: 1-2 Working Days

Shipping costs displayed in basket.

For delivery Tuesday, Dec 24th - order in:

days hrs mins secs

Subject to stock availability, if products on a 24 hours service are ordered alongside products NOT on a 24 hours service, this may delay your whole order.

View Transport Policy

View full product details

View questions about this product

Create a wishlist

STEPHEN HUNTER

Description

To create a pleasing visible stepped appearance and a continuous line on the underside, this dry verge comes in various colours and a choice of left-hand, right-hand and universal configurations. As a result, it encourages rainwater run-off away from the wall and limits the risk of staining.

Features & Benefits: Manthorpe SmartVerge Polypropylene Dry Verge

UV-stabilised polypropylene dry verge system
Suitable for small and large format concrete interlocking tiles from 382mm x 227mm up to 430mm x 380mm
For roof pitches between 15° and 55°
Easy to install without the need for mortar
Creates a pleasing visible stepped appearance and a continuous line on the underside to encourage rainwater run-off away from the wall
255mm to 345mm batten gauge compatibility

For tiles laid between 255mm to 345mm batten gauge, the SmartVerge® Polypropylene dry verge pieces slot over each tile in succession. After installation, the system is fully weatherproof and requires no maintenance. The dry verge system also features eaves closure fixes at the base, which fixes the first unit securely. For enhanced protection at the end of the ridge, angled and round ridge end caps can be purchased.

Suitable for fixing in all weather conditions, Manthorpe SmartVerge® Polypropylene complies with the mechanical fixing requirements of BS 5534 and is independently BRE tested.

Standards & Certification

Complies with the mechanical fixing requirements of BS 5534
Independently BRE tested

Specification

Details

Type Dry Verge Colour Black
Brown
Grey
Terracotta Material Polypropylene Left Or Right Handed Left Handed
Right Handed
Universal

Downloads

There are no product downloads to show.

Questions & Answers

Question:

Are these dovetail products

Answer:

NO They are Manthorpe made

Question:

It mentions the dry verge product is UV-stabilised and if so how long would you expect the product to last before colour fading and discolouring due to the UK weather and sunlight.

Answer:

In ideal conditions, I would expect 8/10+ years - However, I can't get any technical data to back that up

Question:

Will the colour go dull like others I’ve seen already fixed (other brands)

Answer:

Over a very long period of time.

Question:

Can these be fitted to an existing tiled roof where the pointing needs to be repaired

Answer:

Yes these are suitable for down the verge, but best to check the batten guage of your tiles to make sure they will fit.

Batten Gauge Compatibility: 255mm to 345mm

Question:

Hi can these be fitted to existing roof tiles? I tried with another make of dry verge system and they don’t sit right thanks

Answer:

They can but you would need to run a batten down the verge to be able to fix them to.

If you view the installation guide pdf above you can see the fixing method to see if suitable for you.

Question:

Are these interlocking and do you need to buy left hand and right hand?

Answer:

Yes these interlock and they are handed so you need LH and RH for either side of the gable end. If you have a look at the PDF guides above it has more information showing this on installation.

Question:

can this system be used on marley double roman tiles?

Answer:

Yes these will suit as long as your batten gauge is no more than 255mm to 345mm (which it should not be for Double Romans).

Question:

Will fit my tile type. I have Marley modern tiles 420mm long by 330 wide.

Answer:

Yes these will suit as long as your batten gauge is no more than 255mm to 345mm (which it should not be for Moderns).

Question:

hi there, is this product suitable for use with Redland 49 tiles , regards , les.

Answer:

Yes this will be suitable for Redland 49s.

Question:

Manthorpe smartverge,can these be fitted retrospectively as a repair to missing edging roof cement?

Answer:

Yes they can, you may just need to run a batten down the verge to be able to fix them to. If you view the installation guide in the pdf section above it shows this in more detail.
