A UV-stabilised polypropylene dry verge system that is suitable for small and large format concrete interlocking tiles, from 382mm x 227mm up to 430mm x 380mm, on roof pitches between 15° and 55°, this Manthorpe SmartVerge® Polypropylene Dry Verge is easy to install without th... Read More
SUPER Rewards Earn points and build more across our SUPERSTORES!
Find out moreA UV-stabilised polypropylene dry verge system that is suitable for small and large format concrete interlocking tiles, from 382mm x 227mm up to 430mm x 380mm, on roof pitches between 15° and 55°, this Manthorpe SmartVerge® Polypropylene Dry Verge is easy to install without the need for mortar.
To create a pleasing visible stepped appearance and a continuous line on the underside, this dry verge comes in various colours and a choice of left-hand, right-hand and universal configurations. As a result, it encourages rainwater run-off away from the wall and limits the risk of staining.
For tiles laid between 255mm to 345mm batten gauge, the SmartVerge® Polypropylene dry verge pieces slot over each tile in succession. After installation, the system is fully weatherproof and requires no maintenance. The dry verge system also features eaves closure fixes at the base, which fixes the first unit securely. For enhanced protection at the end of the ridge, angled and round ridge end caps can be purchased.
Suitable for fixing in all weather conditions, Manthorpe SmartVerge® Polypropylene complies with the mechanical fixing requirements of BS 5534 and is independently BRE tested.
There are no product downloads to show.
Question:
Are these dovetail products
Answer:
NO They are Manthorpe made
Question:
It mentions the dry verge product is UV-stabilised and if so how long would you expect the product to last before colour fading and discolouring due to the UK weather and sunlight.
Answer:
In ideal conditions, I would expect 8/10+ years - However, I can't get any technical data to back that up
Question:
Will the colour go dull like others I’ve seen already fixed (other brands)
Answer:
Over a very long period of time.
Question:
Can these be fitted to an existing tiled roof where the pointing needs to be repaired
Answer:
Yes these are suitable for down the verge, but best to check the batten guage of your tiles to make sure they will fit.
Batten Gauge Compatibility: 255mm to 345mm
Question:
Hi can these be fitted to existing roof tiles? I tried with another make of dry verge system and they don’t sit right thanks
Answer:
They can but you would need to run a batten down the verge to be able to fix them to.
If you view the installation guide pdf above you can see the fixing method to see if suitable for you.
Question:
Are these interlocking and do you need to buy left hand and right hand?
Answer:
Yes these interlock and they are handed so you need LH and RH for either side of the gable end. If you have a look at the PDF guides above it has more information showing this on installation.
Question:
can this system be used on marley double roman tiles?
Answer:
Yes these will suit as long as your batten gauge is no more than 255mm to 345mm (which it should not be for Double Romans).
Question:
Will fit my tile type. I have Marley modern tiles 420mm long by 330 wide.
Answer:
Yes these will suit as long as your batten gauge is no more than 255mm to 345mm (which it should not be for Moderns).
Question:
hi there, is this product suitable for use with Redland 49 tiles , regards , les.
Answer:
Yes this will be suitable for Redland 49s.
Question:
Manthorpe smartverge,can these be fitted retrospectively as a repair to missing edging roof cement?
Answer:
Yes they can, you may just need to run a batten down the verge to be able to fix them to. If you view the installation guide in the pdf section above it shows this in more detail.
