Corolux Mini PVC Corrugated Roof Sheets

Code:

COROLUX-PVC-MINI-COR

Brand:

Corolux

This highly versatile Mini PVC corrugated roof sheet is available in a range of lengths and is ideal for both roofing and cladding for a variety of uses. Applications include lean-to extensions, garden sheds, covered walkways and side cladding, as well as plant houses, cloches... Read More

View full product details

View questions about this product

Length

Colour

from

£11.76 Incl. VAT

Earn points

Delivery from: 3-5 Working Days

Shipping costs displayed in basket.

View Transport Policy

View full product details

View questions about this product

Create a wishlist

NIGEL BRAY

Description

With an option for a clear or translucent appearance, this roof sheet is visually appealing, enhancing the aesthetic of your property with fine optical clarity. Providing three times more natural light into a building than vertical glazing, this PVC sheet creates a pleasant and bright environment for the area beneath. This lightweight and durable roof sheet is straightforward to handle and install as it is workable. Drilling and cutting are easily completed with standard tools.

Features & Benefits: Corolux Mini PVC Corrugated Roof Sheets

Service temperature range of -20°C to +60°C
Excellent fire performance
Strong yet lightweight
Easy to handle and install
Superb optical clarity
Range of sizes
Variety of uses
10-year warranty

Fixing requirements can easily be calculated by dividing the roof width by the fixing centres, dividing the roof length by the support centres and adding 1, and then finally multiplying these two values together for an approximate number of fixings needed.

With excellent fire performance, the PVC material will melt away from flames. As soon as the source of ignition is taken away, it will stop.

Please note:

A replacement is provided free of charge if the product has failed due to a manufacturing defect, in normal climatic conditions within a 10-year period from the date of purchase.
Corolux MUST be fixed and maintained in accordance with the manufacturer's instructions for the warranty to remain valid. Re-erections or consequential damage costs are not included.
Storage indoors on a dry and flat surface in cool surroundings is preferable. When outdoor storage is unavoidable, store flat on wooden bearers, spaced at about 1m (3' 3") centres and cover completely with an opaque light coloured tarpaulin.
Stacked sheets left uncovered in direct sunlight will distort due to solar heat gain in the stack.
These products cannot be manually offloaded on delivery, if you do not have offloading and required assistance please contact our sales team prior to ordering.

Specification

Dimensions

Length 1830mm
2440mm
3050mm Width 662mm

Details

Thickness 0.8mm Colour Clear
Translucent Material PVC Profile Corrugated
Mini

Downloads

There are no product downloads to show.

Questions & Answers

Question:

What is the cover width per sheet as I have a width of 6600mm

Answer:

11 sheets

Question:

Do u do 10ft in this an what is cost

Answer:

3050mm is just over 10 feet

Question:

What is the horizontal distance (pitch) between the corrugations? I'm looking for sheeting to match an existing roof and it's about 75mm ridge centre to ridge centre.

Answer:

Have a look at this link

https://www.roofingsuperstore.co.uk/user-guides-brochures/ariel_plastics_vistalux_corrugated_pvc_sheet_a5_product_guide_sept_2020.html

Question:

How many sheets (and which size) would I need to cover a pergola measuring 4mX3m please

Answer:

I have sent you a quote

Question:

What’s the sheet coverage when overlapped?

Answer:

The cover width for these is 603mm.

Question:

Hi, is it at all possible that I could get 2x1.53m from each length?

Answer:

This unit comes in three sizes only 3050mm, 2440mm and 1830mm

Question:

How easy is it to cut into shorter lengths (ie across the corrugations), and what tool is required?

Answer:

Cutting instructions can be found here

https://www.roofingsuperstore.co.uk/user-guides-brochures/ariel-corolux-installation-guide.html

Question:

Are these the ones with a blue tint? - - and also the smaller radius wave not the big one!

Answer:

These are translucent in colour.

Question:

which fixings should i use with these mini sheets?

Answer:

Good Morning May

https://www.roofingsuperstore.co.uk/product/corolux-miniature-roof-fixings-pack-for-mini-profiles-pack-of-200.html

Question:

What is the horizontal distance (pitch) between the corrugations? I'm looking for sheeting to match an existing roof and it's about 33mm ridge centre to ridge centre.

Answer:

Good Afternoon Mike

I will send you a personal email with a PDF attached showing the sizes

Question:

hi, can these sheets be cut in half, or is it possible for you to cut them for me, thanks

Answer:

We cannot cut them for you before dispatch but they can be cut on site, using a fine toothed saw.

Question:

Are these sheets waterproof?

Answer:

Yes these are PVC so will not let in water if installed correctly.

Question:

What do you advise to fit Corolux Mini pvc sheets to joists on pergola?

Answer:

You can use the fixings linked below.

https://www.roofingsuperstore.co.uk/product/corolux-miniature-roof-fixings-pack-for-mini-profiles-pack-of-200.html

Question:

How much over lap do you recommend?

Answer:

The cover width of these after overlapping is 603mm. If sheets need to be joined end to end, ensure an overlap of at least 150mm for a 10° slope or 300mm for a 5° slope.

Question:

Is this product compatible with mini Onduline bitumen sheets?

Answer:

Unfortunately not, these sheets do not match the profile of the Onduline mini.
